VLF Series
· Advanced Spur Gear Heat Treatment.
· High Cost Performance & Rapid Delivery.
· Complete Range & Market Versatility.
· Full Size Coverage (VLF078).
| VLF Series Gearbox Performance Information | ||||
|---|---|---|---|---|
| Model | Unit | VLF078 | Ratio | Stage |
| Rated Output Torque | N·m | 92 | 5 | 1 |
| 41 | 9 | |||
| Emergency Stop Torque | N·m | 2 times Rated Output Torque | - | 1 |
| Nominal Input Speed | rpm | 3000 | - | - |
| Maximum Input Speed | rpm | 6000 | - | - |
| Maximum Radial Force | N | 2000 | - | - |
| Maximum Axial Force | N | 1800 | - | - |
| Efficiency | % | Single [97%] | - | - |
| Average Lifetime | h | 2000 | - | - |
| Weight | kg | 3.7 | - | 1 |
| Moment of Inertia | kgcm² | 0.291 | 5 | 1 |
| 0.12 | 9 | |||
| Noise | dB | 65 | - | - |
| Lubricating | - | Synthetic grease lubrication | - | - |
| Levels of Protection | - | IP65 | - | - |
■ Features For VLF Series Planetaty Gearbox ( Spur Gear )
The VLF Series Right-Angle Planetary Gearbox (VLF078) is a high-precision motion control component engineered specifically for space-constrained industrial automation and servo drive applications. Featuring a 90-degree right-angle corner design combined with high-torque planetary mechanics, the VLF078 model effectively eliminates axial mounting constraints while maintaining high power transmission efficiency and superior torsional rigidity. Internal alloy steel gears undergo rigorous carburizing, quenching, and precision tooth grinding, ensuring outstanding tooth surface durability, high positioning accuracy, and remarkably low operational noise. Encased in a rugged housing with a square output mounting flange, it offers excellent mounting stability and resistance against heavy radial and axial forces. The VLF078 right-angle planetary gearbox is an ideal choice for packaging equipment, CNC machinery, robotic automation, conveyor drives, and precision motion systems requiring compact, high-efficiency power transmission.
